Thermo King Precedent S-600
The Precedent S-600 reefer delivers double-digit fuel savings and Thermo King reliability and performance. Plus, its evergreen CARB compliant engine makes it a 50‑state solution.
Why the S-600
Double-digit fuel savings
Because it is certified CARB Evergreen, you can enjoy double-digit fuel savings for the long haul, without the need for a DPF.
A 50-state solution
Its evergreen CARB compliant engine, the TK488CR, makes the S-600 a 50-state solution, with CARB Evergreen certification since 2013.
TracKing telematics built in
Factory equipped with complimentary TracKing telematics, which helps monitor temperature and detects fuel loss.
Accurate temperature sensing
Two return air sensors are positioned to represent accurate trailer compartment temperatures, with sensor accuracy within ±0.47°F.
Cooling capacity at 35°F
The S-600 is rated 60,000 BTU/hr at 35°F on engine power with ETV, at 100°F ambient and high speed engine operation.
Lower refrigerant carbon footprint
R452A provides a lower Global Warming Potential (GWP) and reduces the carbon footprint of refrigerants used by fleets by nearly 50%.
Overview
- 60,000BTU/hrCooling at 35°F, engine power with ETV
- 59,500BTU/hrHeating at 35/0°F ambient, engine power with ETV
- 50statesAn evergreen CARB compliant engine, certified since 2013
- 24monthsOf complimentary TracKing telematics, factory equipped
The S-600 builds on the same benefits as the C-600 but adds an evergreen CARB compliant engine, the TK488CR, for a 50‑state solution. It has held CARB Evergreen certification since 2013 and uses R452A refrigerant.
Built for all 50 states.
What Thermo King built into the S-600, from the engine to the controller.
Evergreen, so no DPF.
The S-600 runs Thermo King’s evergreen CARB compliant engine, the TK488CR, and has held CARB Evergreen certification since 2013. That means double-digit fuel savings for the long haul, without the need for a DPF, today or down the road.
- Evergreen CARB compliant engine (TK488CR)
- No need for a Diesel Particulate Filter (DPF)
- Delivers double digit fuel savings
- R452A refrigerant, to reduce the carbon footprint of refrigerants used by fleets by nearly 50%
Set by the cargo.
The Smart Reefer SR-4 controller runs OptiSet Plus cargo profiles for maintaining product integrity, with ServiceWatch maintenance monitoring and USB service diagnostics.
- Over 500 OptiSet Plus cargo profiles
- Two return air sensors, with sensor accuracy within ±0.47°F
- Running and pretrip diagnostics
- Proprietary eco-pulldown technology
Connected from the factory.
Every S-600 comes factory equipped with 24 months of complimentary TracKing telematics. It helps monitor temperature, offers rapid alarm detection and security alerts when the doors are opened, and detects fuel loss.
- Fleet overview, fleet performance and readiness score dashboards
- Fuel and maintenance reporting
- Full remote control of your refrigerated fleet
Electric standby, your call.
SmartPower electric standby is an option, in Standard and High Output (HO) versions, as is a SmartPower prep package. On electric power the S-600 is rated at 57,000 BTU/hr at 35°F and 19,000 BTU/hr at -20°F.
Built for the road.
Hardware on the S-600.
- Condenser grillesImproved protection from road debris that can impact the condenser coil, and a stronger, more integrated look
- Composite doorsLong-life door panels with auto-latch and auto secondary latch on the front doors
- Fuel systemCommon rail fuel injection with real-time monitoring, and a 2-stage fuel filtration system
- Fuel tank50-gallon aluminum undermount tank with a visual fuel level gauge
- Alternator37 amp extended life alternator; a 65 amp alternator and 30 amp battery charger are optional
- Coils and evaporatorMicrochannel condenser coils and a 2-speed evaporator
Compare the S-600.
Side by side with another single-temperature Precedent, with only the differences showing.
Every Precedent side by sideUnit specs
Specs for the S-600, with their test conditions.
Refrigeration capacity
| Box temperature | Engine Power w/ETV | Electric Power |
|---|---|---|
| 35°F | 60,000 BTU/hr | 57,000 BTU/hr |
| 0°F | 32,000 BTU/hr | 32,000 BTU/hr |
| -20°F | 19,000 BTU/hr | 19,000 BTU/hr |
System net cooling capacity at 100°F ambient and high speed engine operation. Electric power: Thermo King offers several electric standby options; ask your shop about performance on the one you choose.
Heating capacity
| Engine Power w/ETV | 59,500 BTU/hr |
|---|
System net heating capacity at 35/0°F ambient.
Airflow capacity
| Volume at 0 Pa static pressure | 3,350 ft³/min |
|---|
Engine
| Model | TK488CR |
|---|---|
| RPM at High Speed | 2,050 |
| RPM at Low Speed | 1,250 |
| HP Rating at 2,050 RPM | 33 |
| Oil Capacity | 12 qt |
| Maintenance Interval | 3,000 hrs/4,000 hrs |
Four cylinder, direct injection, liquid cooled.
Compressor
| Model | X430L |
|---|---|
| Displacement | 30.0 in³ |
Lightweight aluminum alloy body, heads and sump.
Refrigerant
| Type | R452A |
|---|---|
| Charge | 14.5 lbs |
Zero Ozone Depletion Potential (ODP), internationally approved.
Weight
| System | 1,888 lbs |
|---|---|
| 50 gallon fuel tank (with bracket) | 76 lbs |
Wet with battery.
CARB/EPA compliance
| California Air Resources Board (CARB) | Evergreen Certification since 2013 |
|---|---|
| EPA | Complies with highest possible EPA standards (>25HP Tier IV) |
Standard and optional
- StandardSmart Reefer® SR-4 controller for superior temperature control · Factory equipped with 24 months complimentary TracKing® Telematics · ServiceWatch enabled for maintenance monitoring · OptiSet® Plus cargo profiles for maintaining product integrity · Diesel Direct Electric (DDE) architecture for maximized fuel efficiency · Common rail fuel injection with real-time monitoring · 2-stage fuel filtration system · Microchannel condenser coils · 2-speed evaporator · Simple user interface with USB service diagnostics · 50-gallon aluminum undermount fuel tank w/visual fuel level gauge
- OptionsTemperature data logger for enhanced load protection · Customizable appearance: LED lighting kit, Chrome package · Arctic package · Severe duty package · ThermoLite® solar panels · Alternator, 65amp, 12Vdc · Battery charger · Supplemental power kit · SmartPower™ prep package · SmartPower™ electric standby: Standard and High Output (HO) options
Resources
Spec sheets, brochures and manuals for the S-600. Each opens on thermoking.com.
Every spec sheet and manual- Spec sheetPrecedent S-600 specification sheetPDF · 193 KB · TK 55821-2-PLOpen Precedent S-600 specification sheet (PDF, opens in a new tab)
- Operator's manualPrecedent single-temperature units operator's manual (C-600, S-600 and S-700)PDF · 3 MB · TK 56218-2-OPOpen Precedent single-temperature units operator's manual (C-600, S-600 and S-700) (PDF, opens in a new tab)
- Installation manualPrecedent C-600, S-600 and S-700 installation manualPDF · 65 MB · TK 55496-2-IMOpen Precedent C-600, S-600 and S-700 installation manual (PDF, opens in a new tab)
- BrochureTrailer portfolio brochurePDF · 3 MB · TK 56862-3-PLOpen Trailer portfolio brochure (PDF, opens in a new tab)
- Warranty statementEPA and ARB supplemental emissions warranty statementPDF · 189 KB · TK 56690-9-WAOpen EPA and ARB supplemental emissions warranty statement (PDF, opens in a new tab)
Keep it running.
The service, parts and plans behind every unit TKSE sells.
Service Factory-trained technicians at seven shops, and mobile service trucks that come to the unit.
Parts Every TKSE shop has a parts department with genuine Thermo King parts.
Guaranteed Maintenance Thermo King's fixed-cost agreement for planned and unscheduled maintenance and breakdown repairs. Your shop sets it up.
Get a quote on the Precedent S-600.
Tell us what you need and pick your shop. Or call and talk it through.
- Seven shops in Florida, Georgia and Mississippi.
- Factory-trained technicians, with ongoing training.
- A parts department at every shop.
- Service trucks that come to the unit.
Questions
About the S-600. Anything else, call your shop.
Can I run the S-600 in California?
Yes. The S-600 has held California Air Resources Board (CARB) Evergreen Certification since 2013, and its evergreen CARB compliant engine makes it a 50-state solution. It needs no DPF, today or down the road.
S-600, S-700 or C-600?
The S-600 builds on the same benefits as the C-600 but adds an evergreen CARB compliant engine for a 50-state solution. For a single-zone fleet that operates in California, the S-600 is the pick, or the S-700 if the fleet operates at a -20°F set point more than 50% of the time. For fleets that don’t operate in California, it’s the C-600.
What refrigerant does it use?
R452A, with a 14.5 lb charge. It reduces the carbon footprint of refrigerants used by fleets by nearly 50%.
Is telematics included?
Yes. The S-600 comes factory equipped with 24 months of complimentary TracKing telematics.
How often does the engine need service?
The maintenance interval is 3,000 hrs/4,000 hrs. Your shop can tell you which applies to your unit.
Can it run on electric power at the dock?
With an option: SmartPower electric standby, in Standard and High Output (HO) versions, plus a SmartPower prep package. On electric power the S-600 is rated at 57,000 BTU/hr at 35°F. There are several electric standby options, so ask your shop for the performance of the one you choose.
What options can I add?
A temperature data logger, LED lighting and chrome appearance options, an Arctic package, a severe duty package, ThermoLite solar panels, a 65 amp alternator, a battery charger, a supplemental power kit, and SmartPower prep or electric standby.
Does Thermo King’s Extended Warranty cover it?
Thermo King’s Extended Warranty covers the Precedent S-600 / S-700 / C-600, with full-unit and major-component options. Ask your shop for the terms.
